Description
SPECIFICATION
NOMINAL IMPEDANCE 4 ohms
RECOMMENDED AMPLIFIERS 20 to 180 watts
FREQUENCY RESPONSE 28Hz-30kHz
SENSITIVITY 90 dB linear for 1 watt at 1 metre
BASS /MIDRANGE DRIVERS 2x 6.5” bass/mid units. One driver with Pagina Mica cone and open weave dust cap and one driver with polypropylene cone with soft polypropylene dust cap. Both units working in tandem.
TWEETER ProAc 1” silk dome tweeter
CROSSOVER Specially designed crossover to accommodate two different types of bass/mid cones. Glass fibre board with finest components using multistrand copper wire designed for use with both Bi-amping and Bi-wiring.
HEIGHT (CABINET) 978mm on spikes(38.5”)
WIDTH (CABINET) 193mm (7.6”)
DEPTH (CABINET) 229mm (9”)
WEIGHT 26kg each (55lb)
MODE Stand mounting
GRILLE Acoustically transparent crimplene
STANDARD FINISHES Black Ash, Mahogany, Cherry, Oak, Silk White and Walnut
PREMIUM FINISHES Rosewood, Ebony. *Premium Finishes to order at extra cost*
