Description
SYSTEM
Sealed box loading, single driver, active subwoofer
SPEAKERS
1 x 320 mm (12”), long throw, sandwich honeycomb cone, wide rubber surround LF unit
AMPLIFICATION
High performance, Class AB
850 W (nominal), 1,200 W (peak)
FREQUENCY RESPONSE
20 Hz (@- 6 dB, acoustic Linkwitz 4th order roll-on, default setting) to Fc (user continuously adjustable)
MAINS INPUT VOLTAGE
100-120 Vac – 50/60 Hz or 220-240 Vac – 50/60 Hz
FUSE
T12A H250V (100-120 Vac – 50/60 Hz)
T6.3A H250V (220-240 Vac – 50/60 Hz)
CONTROLS
Direct access Master volume;
APP control featuring: 4 selectable presets, volume, continuously adjustable crossover frequency (40 to 150 Hz , filtering slope 24 dB/oct); continuously adjustable signal phase (0° to 360°); up to 8 parametric EQ filters , Delay (1 to 20 ms); automatic room calibration ; selectable threshold auto power on/off
AUDIO SIGNAL INPUTS
2 x LINE (unbalanced), Left and Right/LFE – RCA plugs
2 x LINE (balanced), Left and Right/LFE – XLR plugs
HIGH LEVEL – Neutrik 4-pole Speakon© plug
POWER CONSUMPTION
< 2 W (Stand-by)
1,000 W (rated power)
DIMENSIONS (HXWXD)
455 x 448.5 x 448.5 mm
18 x 17.6 x 17.6 in
WEIGHT
32 Kg
70.5 lb
