Description
Moving Magnet
Mass & Dimension
6.0g, 11.6 x 20.26 x 27.24mm (WxHxD)
Stylus
0.3 x 0.7mil Elliptical
Cantilever
Aluminum Pipe
Coils
High-Purity Copper
Internal Impedance
1,130Ω
Load Impedance
47kΩ
Frequency Response
12Hz – 30kHz
Output
4mV @ 1kHz
Channel Separation
30dB @ 1kHz
Channel Balance
0.5dB @ 1kHz
Compliance
12×10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
25°
Tracking Force Range
1.5g – 2.0g
Recommended Tracking Force
2.0g
Replacement Stylus Unit
RS Pearl
